Integrated 17" LED screen/keyboard/mouse/switcher in a single unit;

   LCD display adjustment function, rail with self-locking device;

   Pull-out installation design, adjustable length to fit each cabinet space.

   Support Microsoft IntelliMouse (Pro), Optical, Mouse Man.

   Wheel Mouse, Scroll Point, Serial Mouse, etc.

   automatically record and store the original working status of the keyboard when switching computers.

   Hot-key function provides more convenient management operations;

   Auto-scan function enables KVM to automatically scan computers one by one;

   Auto-scan can be set via the OSD view control menu for easy management;

   Complete DDC2B function to detect the screen model even when the computer is not switched;

   Excellent video effect, best resolution up to 1280*1024 75HZ;

   Dual interface PS/2 /USB keyboard and mouse switch to control computer;

   Can cascade multiple devices, 16 ports can be connected to 512 computers for unified operation;

   Humanized design, one person can install and remove, improve the efficiency of the administrator;

Computer connection: 8/16 computers, switching cascade up to 512

Connection cable port

USB VGA cable; front USB interface (can be connected to the mouse keyboard, can not read U disk)

LCD display

17" TFT material LED screen; 1280*1024@75HZ resolution; 16.7M max color; 300nits brightness; 700:1 contrast ratio; 0.297 x 0.297 mm pixel pitch

Keyboard/Mouse: 104 keys laptop keyboard Touchpad touchpad

Power input: AC100-240V 47-63Hz, 35W

Material process: high strength anti-corrosion plate gold

Appearance color: black high-temperature spray paint scattered points

Size ( L * W * H ): 568mm * 475mm * 44mm

Gross weight: about 17.5KG

Installation cabinet: 800-1040mm

Storage temperature: -20℃~70℃

Working temperature：0℃~60℃

Humidity：0%-80%RH
