High load-bearing and high strength, suitable for load-bearing requirements

High protection level, suitable for harsh environment such as outdoor or wet

Anti-vibration, can be used in car and other vibration environments

Electromagnetic shielding and electrostatic shielding, effectively shielding electromagnetic or electrostatic interference

●Personalized and customized, multiple types, non-standard, etc.

Combined control cabinet, suitable for combined cabinet use

The top panel can be removed and the side panels can be disassembled, making it easier to work conveniently

The door panel is very high from the ground, about 25mm, which ensures the flexibility and smoothness of opening the door

●Unique nine-fold profile

●Special square tube reinforcement system of the door panel can be screwed to the door panel for easy removal

●Dense 25mm spacing modulus holes on the frame ensure flexibility and versatility of installation

Optional 3.0mm galvanized mounting plate can be pushed into the cabinet from the front by plastic sliders through the guide rails, and the two sides have U-shaped folded edges to make the mounting plate more solid and easier to carry.

Material: cold rolled steel

Surface treatment: cabinet phosphate primer treatment, the exterior of the cabinet is powder coated, the color can be divided into RAL7032 and RAL7035 two kinds of weave pattern, the mounting plate is galvanized

Protection grade: IP56 (according to GB4205-1993)

Standard configuration: front door, back panel, mounting plate, cabinet body, sealing strip, door lock, side panel (optional)

Steel plate thickness:

Frame: nine-fold profile 1.5mm

Door plate: 2.0mm

Back plate, side plate: 1.5mm

Mounting plate: 2.5mm (optional 3.0mm)
