Material: box steel plate 1.5mm. Door steel plate 2.0mm, surrounded by foam polyurethane plastic sealing ring. Mounting plate plate 3.0mm

surface: cabinet and door dip primer, powder coating, weaving. Mounting plate: Galvanized

color: RAL 7035

Protection grade IP, according to IEC 60 529 standard: IP 66

Scope of Supply: Case with hinged door, three-point lock system with double-toothed lock core, mounting plate open at bottom for personalized cable introduction

Basic materials: Steel plate

size: Width 180mm height 254mm depth 90mm

Mounting plate: Width 170mm height 245mm

Number of doors :1

Door hinge on the right, can be changed to the left :yes

Packing unit :1 piece

weight/packaging: 39kg
