Outdoor communication cabinet>TA-DB Type of outdoor thermal control cabinet with light shade
● Shading panels are set on both sides, facade and top surface to inhibit the internal temperature rise caused by radiant heat. ● The steering wheel is easy to open and close by pulling up, and the outer plane steering wheel with strong fastening and holding force can be locked. ● The hand is configured on the outside of the body intermouth, which will not affect the storage space. ● Excellent weather resistance. (WP40H) |
Product specification
Product Model | TRA-34 | TRA-45 | TRA-54 | TRA-56 | TRA-58 | TRA-65 | TRA-68 |
weight(mm) | 360 | 460 | 560 | 560 | 560 | 660 | 660 |
height(mm) | 436 | 536 | 436 | 636 | 836 | 536 | 836 |
depth(mm) | 230 | 230 | 230 | 230 | 230 | 230 | 230 |
product weight(KG) | 11.5 | 16.8 | 16.7 | 23.5 | 30.0 | 23.2 | 34.6 |
